What are the types of GE oilles plain bearing?

oilles plain bearing
(1) GE...C type and GE...T type oilles plain bearing: extruded outer ring, outer ring sliding surface is sintered bronze composite material; inner ring is hardened bearing steel, sliding surface is plated with hard chromium, limited to small size Bearing.
The outer ring is made of bearing steel, and the sliding surface is a layer of PTFE fabric. The inner ring is hardened bearing steel, and the sliding surface is plated with hard chromium. It can bear the load in the same direction, and can bear the small axial load in any direction while bearing the radial load.

(2) GE...CS-2Z oils plain bearing: the outer ring is made of bearing steel, and the sliding surface is made of sintered bronze composite material; the inner ring is made of hardened bearing steel, and the sliding surface is plated with hard chromium; with dust cover on both sides. It can bear loads in the same direction, and can bear small axial loads in any direction while bearing radial loads.

(3) GEEW...T-type oils plain bearing: the outer ring is made of bearing steel, and the sliding surface is a layer of PTFE fabric; the inner ring is of hardened bearing steel, and the sliding surface is plated with hard chromium. It can bear the load in the same direction, and can bear the small axial load in any direction while bearing the radial load.

(4) GE...F oilles plain bearing: the outer ring is hardened bearing steel, the sliding surface is glass fiber reinforced plastic with polytetrafluoroethylene as additive, the inner ring is hardened bearing steel, and the sliding surface is plated with hard chromium. Can withstand moderate radial loads in the same direction.

(5) GE...F2 oils plain bearing: the outer ring is made of glass fiber reinforced plastic, and the sliding surface is made of glass fiber reinforced plastic with polytetrafluoroethylene as additive; the inner ring is made of hardened bearing steel, and the sliding surface is plated with hard chrome. Can withstand moderate radial loads in the same direction.

(6) GE…FSA oils plain bearing outer ring is made of medium carbon steel, the sliding surface is composed of glass fiber reinforced plastic discs with PTFE as additive, and is fixed on the outer ring with a retainer; the inner ring is hardened Bearing steel. Used for large and extra large bearings. Can withstand large radial loads.

(7) GE...FIH type outer ring is hardened bearing steel; inner ring is medium carbon steel, and the sliding surface is composed of glass fiber reinforced plastic discs with polytetrafluoroethylene as additive, and is fixed on the inner ring with a retainer; Double half outer ring. Used for large and extra large bearings. Can withstand large radial loads.

Self-lubricating angular contact oilles plain bearing
GAC...F type oilles plain bearing outer ring is hardened bearing steel; sliding surface is glass fiber reinforced plastic with polytetrafluoroethylene as additive; inner ring is hardened bearing steel, sliding surface is plated with hard chromium. It can bear radial load and axial (combined) load in one direction.

Self-lubricating thrust oilles plain bearing
GX...F oilles plain bearing seat ring is hardened bearing steel, sliding surface is glass fiber reinforced plastic with PTFE as additive, shaft ring is hardened bearing steel, sliding surface is plated with hard chrome. Can withstand axial load or combined load in one direction (at this time, the radial load value shall not be greater than 0.5 times the axial load value).
