Do you know structural features of Self-Aligning Double Row Ball Bearings?

663 Published by Aug 21,2018

The Self-Aligning Double Row Ball Bearings is a bearing in which an inner ring of two raceways and an outer ring of a spherical race are fitted with spherical balls.

The center of curvature of the raceway surface of the outer ring is identical to the center of the Self-Aligning Double Row Ball Bearings, so it has the same self-aligning function as the self-aligning ball bearing. When the shaft and outer casing are deflected, it can be adjusted automatically without increasing the bearing load. Spherical roller bearings can withstand radial loads and axial loads in both directions. The radial load capacity is large, and it is suitable for heavy load and impact load. The inner ring inner diameter is a tapered bore bearing that can be mounted directly. Or use the adapter sleeve and the removal cylinder to mount on the cylindrical shaft. The cage uses a steel stamping cage, a polyamide forming cage and a copper alloy cage.

Self-Aligning Double Row Ball Bearings-1
The Self-Aligning Double Row Ball Bearings has two structures of a cylindrical hole and a tapered hole, and the material of the cage is steel plate, synthetic resin and the like. The characteristic is that the outer ring raceway has a spherical shape and has self-aligning property, which can compensate the error of the heart ball bearing by different heart degree and shaft deflection, but the relative inclination of the inner and outer rings must not exceed 3 degrees.
Self-Aligning Double Row Ball Bearings-2

Can withstand large radial loads while also withstanding a certain axial load. The outer ring raceway of this type of Self-Aligning Double Row Ball Bearings is spherical, so it has the function of self-aligning. When the shaft is bent or tilted so that the center line of the inner ring and the center line of the outer ring are inclined no more than 1°~2.5°, the bearing can still work. .
The inner diameter of the Self-Aligning Double Row Ball Bearings is cylindrical or conical. The conical inner bore has a taper of 1:1 2 or 1:30. In order to enhance the lubrication performance of the bearing, an annular oil groove and three oil holes are machined on the outer ring of the bearing.

Self-Aligning Double Row Ball Bearings-3
Product Features of Self-Aligning Double Row Ball Bearings:
It is mainly subjected to radial loads and can withstand small axial loads. The axial displacement of the shaft (outer casing) is limited to the clearance limit, and has automatic self-aligning performance, allowing normal operation under the condition that the inner and outer sides are relatively inclined, and is suitable for the parts in which the support seat hole cannot strictly guarantee the coaxiality.

Self-Aligning Double Row Ball Bearings-4
structure type of Self-Aligning Double Row Ball Bearings:
Self-Aligning Double Row Ball Bearings with dust caps and seals are filled with the right amount of grease. They should not be heated or cleaned before installation. No lubrication is required during use. Adapt to operating temperature - 30 °C to + 120 °C. between. Main purpose of self-aligning ball bearings: Suitable for precision instruments, low noise motors, automobiles, motorcycles and general machinery, etc. It is the most widely used type of bearing in the machinery industry.
